เมนบอร์ด 775 G31LMS มือ2

คุณสมบัติสินค้า:

Brand Longwell (LWC) Model G31LMS CPU Support "• Intel® Celeron • Intel® Celeron D • Intel® Celeron Dual-Core • Intel® Core 2 Duo • Intel® Pentium 4 • Intel® Pentium D • Intel® Pentium Dual Core Socket LGA775

Share

หมวดหมู่ : Mainboard

แบรนด์ : LWC

Share

Brand Longwell (LWC)
Model G31LMS
CPU Support "• Intel® Celeron
• Intel® Celeron D
• Intel® Celeron Dual-Core
• Intel® Core 2 Duo
• Intel® Pentium 4
• Intel® Pentium D
• Intel® Pentium Dual Core
Socket LGA775
Memory Dual Channel DDR2 Memory Technology
2 x DDR2 DIMM Slots
2 x DDR2 667/800 MHz
Max.capacity up to 4GB Memory
Chipset Intel G31 Express North Bridge and Intel ICH7 South Bridge chipsets
Audio "• Supports 6 channels sound input( ex: Realtek ALC662)
• Supports 16-bit ADC (Analog Digital Converter)
• Supports multipls stereo input mixer
Expansion Slot 1 x PCI Express 2.0 x16 (x16 mode)
2 x PCI Slot
Storage 2 x SATA2 Connector
1 x IDE Port
Internal I/O Connectors 1 x 24-pin EATX Power Connector
1 x 4-pin ATX 12V Power Connector
1 x CPU Fan Connector
2 x F USB 2.0 Connector
1 x Front Panel Audio Connector (AAFP)
1 x Speaker Connector
1 x System Panel Connector
Back Panel Connectors 1 x PS/2 Mouse Port
1 x PS/2 Keyboard Port
1 x VGA (D-Sub) Port
1 x Serial Port (Com1)
1 x Parallel Port (LPT)
2 x USB 2.0 Port
1 x LAN (RJ45) Port
3 x Audio Jacks: Line in / Speaker / Microphone
LAN 10/100 Mb/s auto negotiation Half/Full duplex capability
Realtek® RTL8105E
Form Factor Micro ATX Form Factor Dimension: 23.9 cm*17.0cm
Operation System Support Microsoft® Window® XP / Vista / 7 / 8 / 10

มีฝาหลัง+สายSata+Driver
ประกัน/Warranty: 30 วัน/days
**สินค้ามือ2 ทดสอบสินค้าก่อนส่งทุกตัว สินค้าส่งจากกทม.**
*รูปถ่ายใช้สำหรับการโฆษณาเท่านั้น*
