Brand: LWC (Longwell)
Model: H310-H3M (Rev.2)
CPU Support:
Support for 9th and 8th Generation
Intel® Core™ i9 / i7 / i5 / i3 / Pentium® / Celeron® processors in the LGA1151 V2 package
Socket: Socket 1151 V2
Chipset: Chipset Intel Q370
Memory Support:
Memory Support 2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
Dual channel memory architecture
Support for DDR4 2666/2400/2133 MHz memory modules
Audio: Audio Realtek® ALC662 codec
High Definition Audio 5.1-channel
Expansion Slots:
1 x PCI Express x16 slot
1 x PCI Express x1 slot Storage
4 x SATA 6Gb/s connectors
1 x M.2 NVME Internal I/O Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
4 x SATA 6Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
1 x USB 3.0 header
1 x USB 2.0 header
1 x TPM 2.0 header
1 x Clear CMOS jumper
Back Panel Connectors:
2 x PS.2 keyboard/mouse port
1 x HDMI port
1 x VGA port
4 x USB 3.0 ports
1 x RJ-45 port
3 x audio jacks
LAN: 10/100/1000 Mb/s auto negotiation Half/Full duplex capability
Realtek® RTL8111H
Smart Fan Mode: Yes (Temperature control)
Form Factor: Micro ATX Form Factor; 21.6 cm x 17.0 cm
**Boot Mode: Support UEFI mode
Windows Support: Win 7-11
Accessories:
1 x SATA cable
1 x I/O Rear Panel
1 x User Manual
